FBT Ventis 108A Powered Speaker


FBT Ventis 108A Powered Speaker


For the VENTIS range, quality and flexibility are the watchwords. Based on a powerful combination of B&C compression drivers and FBT’s own custom, long excursion woofers, the 115, 112 and 110 models are two-way, bass reflex designs housed in 15mm birch plywood. A full-grille design backed by specially treated acoustic cloth delivers the characteristic style for which FBT is known, while fully rotatable constant directivity horns ensure accurate coverage.

The FBT VENTIS range offers powerful DSP with 6 versatile presets. Crafted by expert FBT engineers, the presets offer a performance for every requirement.
ORIGINAL / LIVE The renowned, smooth FBT sound
VOCAL A special EQ setting to maximise speech intelligibility
DJ Designed to keep the energy high and your audience dancing
TOURING The reliability and the roar of the industry’s most popular touring systems
LOUDNESS The ultimate preset for listening at a medium or low volume
WARM A special setting to emphasise full-bodied, low-mid frequencies.

Processed Active Speaker 700W + 200W - 131dB SPL
The 108A includes a 200mm (8”) woofer and 50mm (2”) voice coil, driven by 700W + 200W bi-amplification to deliver an impressive 131dB SPL from a supremely portable cabinet.

2-way bi-amplified, bass-reflex design
200mm (8”) LF woofer with 50mm (2”) voice coil, custom made for FBT
25mm (1”) exit throat B&C HF compression driver with 36mm (1.4”) voice coil
Frequency response from 65Hz to 20 kHz
80°H x 50°V Constant Directivity Rotatable Horn
optional wall bracket mount thread, 35mm (1 3/8”) top-hat
one integrated pocket handle

Configuration:     2 way
Built-in amplifier LF/HF:     700/200 W RMS
Built-in amplifier peak LF/HF:     1400/400 W
Frequency response:     65Hz-20kHz -6dB
Low Frequency woofer:     8 - 2 coil inch
High Frequency driver:     1 - 1.4 coil inch
Maximum SPL cont/peak:     123/131 dB
Dispersion:     80°x50° rotatable HxV
Input impedance:     22 Kohm
AC Power requirements:     640 VA
Input connector:     XLR with loop, RCA ST
Power cord:     5/16.4 m/ft
Net Dimension (WxHxD):     274x500x300 / 10.8x19.7x11.8 mm/inch
Net Weight:     15.6/34.39 Kg/lb
Transport Dimension (WxHxD):     395x620x375 / 15.5x24.4x14.7 mm/inch
Transport Weight:     15.3/33.7 Kg/lb
